Britax Micro Relay 24V 12/15A 5 Pin Change Over SPDT Resistor Protected
by Britax
Original price
$6.85
-
Original price
$6.85
Original price
$6.85
$6.85
-
$6.85
Current price
$6.85
SKU RMC-2425R
Specifications:
| Pull In Voltage: | 16.8V |
| Terminals - Width: | 4.8 & 6.3mm Zinc Plated Terminals |
| Features: | Sealed Relay with IP67 Rating. |
| Contacts: | Silver AgSnO2 |
| Approvals: | ISO9001; QS9000; ISO/TS16949 and ISO14001; CE; UL; CSA and TUV |
| Terminal Material: | Zinc Plated |
| IP Rating: | IP67 |
| Protection: | Resistor |
| Terminal Dimensions: | 3 x 4.8mm; 2 x 6.3mm |
| Brand: | BRITAX |
| Voltage: | 24V |
| Mounting Bracket: | Removable metal bracket |
| Dimensions: | 26(H) x 23(D) x 15.5(W)mm |
| Amperage: | N/C 12A; N/O 15A |
| Coil Power Consumption: | 1.5W |
| Type: | SPDT N/O N/C |
| Terminals - #: | 5 Pin |
